Model
Parameter

DL-10

DL-15

DL-20

DL-25

DL-30

DL-40

DL-50

DL-60

DL-75

DL-100

Air flow m3/min
Pressure Mpa

1.2/0.7

1.65/0.7

2.5/0.7

3.2/0.7

3.8/0.7

5.3/0.7

6.8/0.7

7.4/0.7

10/0.7

13.4/0.7

1.1/0.8

1.5/0.8

2.3/0.8

3.0/0.8

3.6/0.8

5.0/0.8

6.2/0.8

7.0/0.8

9.6/0.8

12.6/0.8

0.95/1.0

1.3/1.0

2.1/1.0

2.7/1.0

3.2/1.0

4.5/1.0

5.6/1.0

6.2/1.0

8.5/1.0

11.2/1.0

0.8/1.2

1.1/1.2

1.9/1.2

2.4/1.2

2.7/1.2

4.0/1.2

5.0/1.2

5.6/1.2

7.6/1.2

10.0/1.2

Lubricant L

10

18

30

65

Noise

66+_2

68+_2

72+-2

Driving way

Direct Driven

Power Supply

380V/50Hz

Power HP

10

15

20

25

30

40

50

60

75

100

Starting way

Y DELTA

Dimension

L mm

900

1080

1380

1500

1700

W mm

670

750

850

1000

1200

H mm

845

1015

1175

1335

1630

Weight KG

220

380

500

700

1200

Outlet pipe diameter

G1/2

G3/4

G1

G1-1/2

G2

Model
Parameter

DL-125

DL-150

DL-175

DL-200

DL-250

DL-300

DL-350

DL-430

DL-480

DL-540

Air flow m3/min
Pressure Mpa

16.2/0.7

21.0/0.7

24.5/0.7

28.7/0.7

32/0.7

36/0.7

42/0.7

51/0.7

64.0/0.7

71.2/0.7

15.0/0.8

19.8/0.8

23.2/0.8

27.6/0.8

30.4/0.8

34.3/0.8

40.5/0.8

50.2/0.8

61.0/0.8

68.1/0.8

13.8/1.0

17.4/1.0

20.5/1.0

24.6/1.0

27.4/1.0

30.2/1.0

38.2/1.0

44.5/1.0

56.5/1.0

62.8/1.0

12.3/1.2

14.8/1.2

17.4/1.2

21.5/1.2

24.8/1.2

27.7/1.2

34.5/1.2

39.5/1.2

49/1.2

52.2/1.2

Lubricant L

72

90

110

125

150

180

Noise

72+_2

75+_2

82+_2

84+_2

Driving way

Direct Driven

Power Supply

380V/50Hz

Power HP

125

150

175

200

250

300

350

430

480

540

Starting way

Y DELTA

Dimension

L mm

1700

2300

2500

3150

W mm

1200

1470

1470

1980

H mm

1630

1840

1840

2150

Weight KG

1200

2000

2200

3500

4000

4500

6000

6500

7200

Outlet pipe diameter

G2

G2-1/2

DN85

DN100
