Medium pressure diesel driven screw air compressor

Model	DL-15/21D	DL-16/16(17/13)D	DL-17/18(18/15)D	DL-25/17D
Air compressor
Exhaust volume m³/min	530	565/600	600	885
Discharge pressure bar	21	16/13	18	17
Compression stage	Double stage compression	Single stage compression	Double stage compression	Double stage compression
Driving mode	Diesel engine driven	Diesel engine driven	Diesel engine driven	Diesel engine driven
Oil air separator capacity L	100	100	100	165
Lubricating oil L	48	48	48	80
Air filter	Fleetguard	Fleetguard	Fleetguard	Fleetguard
Air end	BSC	BSC	BSC	BSC
Diesel engine
Manufacturer	Cummins	Cummins	Cummins	Cummins
Model	QSB5.9-C220-31	QSB5.9-C21030	QSB5.9-C220-31	6LTAA8.9-C325
Rated speed/load/ un-load rpm	2200/1900/1450	2200/1800(2000)/1450	2200/1950/1450	2200/1900/1500
Power KW	157	154	157	239
Cylinders quantity/cylinder diameter/stroke	6×102×120	6×102×120	6×102×120	6×114×145
Displacement L	5.9	5.9	5.9	8.9
Cooler liquid capacity L	20	20	20	50
Oil capacity L	17	17	17	27.6
Fuel tank capacity L	210	210	210	300
Air filter	Fleetguard	Fleetguard	Fleetguard	Fleetguard
Oil filter	WD13145	WD13145	WD13145	P165705
Battery	6QW-165MF	6QW-165MF	6QW-165MF	6QW-200MF
Size/Weight
Length mm	3282 (2780 without trailer)	3282 (2780 without trailer)	3282 (2780 without trailer)	3708 (3500 without trailer)
Width mm	1605	1605	1605	1980
Height mm	2252	2252	2252	2492
Weight Kg	2700	2500	2500	3700
Outlet size	G1"x1&G11/2"x1	G1"x1&G11/2"x1	G1”x1&G11/2”*1	G2"x1&G11/2"x1
